Description
Engine
Engine Type
V Twin
Displacement
48.8 cu. in. (800 cc)
Cylinders
2
Bore x Stroke
Bore: 3.58 in. (91 mm); Stroke: 2.4 in. (61.5 mm)
Engine Cooling
Liquid
Fuel System
Gas
Starting System
Electric
Chassis
Front Suspension
Independent Double A-Arm
Front Travel
8.8 in. (225 mm)
Front Brake Type
Hydraulic Disc
Front Tires
26 x 8 R14
Rear Suspension
Independent A-Arm
Rear Travel
8.8 in. (225 mm)
Rear Brake Type
Hydraulic Disc
Rear Tires
26 x 10 R14
Frame
Steel
Dimensions/Capacities
Towing Capacity
1764 lb. (800 kg.)
Fuel Capacity
6.8 gal. (26 L)
Ground Clearance
11.2 in. (285 mm)
Machine Dimensions (LxWxH)
L: 92.3 in. (2345 mm); W: 49.7 in. (1254 mm); H: 57 in. (1450 mm)
Wheelbase
58.3 in. (1480 mm)
Drive Train
Drive Train
Continuously Variable (CVT)
General
Speedometer
Standard
Tachometer
Standard
Odometer
Standard
Warranty
60
